Gecko S-Class Spa Controller 4kw Heater JJ Connectors 2 Pumps 3-72-7079

DISCONTINUED  see any of the In.YE control system bundles.

see our other Gecko and Balboa control system bundles or contact us for assistance

Gecko S-Class Spa controller 3-72-7079 with 4kw heater and spa pack model SSPA-1-P122-P212-O1-NE-LS-H4.0-JJM-PPD is the spa pak controller for spa S-CLASS type with outputs: pump 1 with 2 speeds 240V, pump 2 with 1 speed 240V, ozonator 120V, (every output's voltage can be reconfigured), heater 4.0kw, connector JJM, works with keypad TSC-9, TSC-18 or TSC-19

S-Class SC-CF-P121-P211-O1-LS-H4-JJC spa pack.

Free shipping in the continental U.S.A. on this complete spa pack with 4kw heater.

This control system by Gecko Alliance is used in many popular spa models.
Need a different pack? Contact us as we offer the full Gecko range.

Cords sold separately if needed - mini J&J cords BDLTSC9PPD

Also replaces pack model 844026.

Need a control panel?

See BDLTSC18GE2 (sold separately) TSC-18 4-button topside for 2 pump systems.

We also offer this TSC-18 with 2 overlays as part  BDLTSC18PPD  (sold separately also known as 0202-007134)

There is also the 1-pump version of the TSC-18 with 1-pump overlay BDLTSC18GE1.

If replacing discontinued Coast or Artesian Gecko spa packs and existing pack has a flow thru heater under the pack, you can use this pack which can use a 3-00-7218a or a 3-72-7019a control.

Other option
A new retrofit option that you can also use which will fit in the same spa is the IN.Ye Control box 3-72-7031 if you have the small 2.5”x4” topside control and 3-72-7033 if you have the 3.25” X 7” topside control.



This item is:SSPA pack 3-72-7079

SSPA-1-P122-P212-O1-NE-LS-H4.0-JJM-PPD
Controller for spa S-CLASS type with outputs: pump 1 with 2 speeds 240V, pump 2 with 1 speed 240V, ozonator 120V, (every output's voltage can be reconfigured), heater 4kW, connector JJM, works with keypad TSC-9, TSC-18 or TSC-19

(see BDLTSC18PPD, BDLTSC19PPD and BDLTSC9PPD)

The Gecko S-Class is comparable to the Gecko in.ye-5 control system. Gecko S-Class series of spa controls presents versatility and compact size all in one package.  Among its many features:

    Automatic time-out on all outputs
    Sensor failure detection
    Ozone management
    Programmable filter cycles
    High-limit protection
    Pressure switch failure detection
    Current limiting option
    Smart Winter Mode
    Temp. accuracy within ± 1°F
    Filter cycle over temp protection

This S-Class control box only contains circuits fitted with Mini JJ style receptacles that will operate the following equipment:

        Pump, 1-Spd or 2-Spd, 115/230v
        Pump, 1-Spd, 115/230v
        Ozone, 115/230v
        Light 12v

  Replaces 0202-205216, 0201-100011 , 0201-201014 , 0202-205002 , 0202-205008 , 0202-205011 , 0202-205013 , 0202-205015 , 0202-205017 , 0202-205018 , 0202-205027 , View More 0202-205031 , 0202-205034 , 0202-205038 , 0202-205040 , 0202-205043 , 0202-205045 , 0202-205069 , 0202-205086 , 0202-205092 , 0202-205097 , 0202-205105 , 0202-205106 , 0202-205118 , 0202-205126 , 0202-205127 , 0202-205130 , 0202-205143 , 0202-205156 , 0202-205201 , 0202-205211 , 0202-205215 , 0202-207005 , 0202-207009 , 3-62-7017 , 3-72-7011 , 3-72-7013 , 3-72-7014 , 3-72-7023 , 3-72-7040 , 3-72-7080 , 3-72-7086 , 3-72-7125 , 3-72-7131 , 3-72-7136 , 3-72-7140 , 3-72-7141 , 3-72-7144 , 3-72-7147 , 301877 , 9305-004 , 9735-116 , 9735-120 , 9735-127.

Identical to 3-72-7079 0201-100011 0201-201014 0202-205002 0202-205008 0202-205011 0202-205013 0202-205015 0202-205017 0202-205018 0202-205027 0202-205031 0202-205034 0202-205038 0202-205040 0202-205043 0202-205045 0202-205069 0202-205086 0202-205092 0202-205097 0202-205105 0202-205106 0202-205118 0202-205126 0202-205127 0202-205130 0202-205143 0202-205156 0202-205201 0202-205211 0202-205215 0202-207005 0202-207009 3-62-7017 3-72-7011 3-72-7013 3-72-7014 3-72-7023 3-72-7080 3-72-7086 3-72-7125 3-72-7131 3-72-7136 3-72-7140 3-72-7141 3-72-7144 3-72-7147.

DISCONTINUED - see our other control systems
